MV HV Oil Immersed Transformer 315kVA to 630kVA 3 Phase Distribution Transformer 60Hz
Key Specifications
| Attribute | Value |
| Frequency | 60Hz |
| Phase | Three, Single Phase |
| Application | Power Transformer |
| Output Voltage | 415V, 380V, 400V, 110V, 220V, 440V, 480V |
| Input Voltage | 11kV, 10.5kV, 6.3kV, 6.6kV, 6kV, 10kV, 35kV |
| Type | Oil-Immersed Transformer |
| Coil | Copper/Aluminum Coil |
| Usage | Power, Distribution Transformer |
| Rated Power | 10-5000 kVA |
| Insulation Class | Class A, Class B, Class F, Class H |
| Cooling | ONAN/ONAF or Customized |
| Material | Copper + Aluminum |
| Transformer Type | S11 Oil-immersed Transformer |
| Impedance Voltage | 4-6% |
| Dielectric | Mineral oil (PCBs is prohibited) |
| Insulation | Mineral Oil |
| Rated Voltage | 6-35 kV |
Product Overview
Hentg Power MV HV Distribution Transformer 315kVA 400kVA 500kVA 630kVA Three Phase Oil Immersed Transformer is designed for optimal performance in power distribution applications.
Certifications & Testing
Compliant with IEC, ANSI, and BS standards, with CE, ISO9001, and type test certificates available. 100% factory-tested for electrical performance and vacuum-dried for insulation reliability. Ensures safe and compliant procurement for global projects with guaranteed performance.
Technology & Design
Type S13 oil-immersed distribution transformer is based on the original S11 distribution transformer, through the research and application of new materials and new technologies and the combination of independent innovation and technology introduction, through the optimization and innovative design of the core and coil structure, to reduce the no-load loss and noise purposes. Compared with the current national standard JB/T10088-2004, the noise level decreased by 20% on average, and the product performance level reached the domestic advanced level.
Ideal distribution equipment for urban and rural distribution network centers.
Key Advantages
- Higher Energy Efficiency - Lower no-load loss: The S13 series uses high-quality silicon steel sheets and optimized magnetic circuit designs, reducing no-load losses by 20-30% compared to S11 models. Lower load loss: Improved winding structure and materials reduce resistance and load losses, improving overall efficiency.
- Improved Temperature Rise Performance - Enhanced oil circulation and cooling systems help maintain stable operation under load. Better thermal management leads to longer insulation life.
- Reduced Noise Levels - Use of high-permeability silicon steel and precision manufacturing lowers magnetostriction, resulting in quieter operation.
- Robust Mechanical Design - Improved short-circuit resistance due to optimized winding structure and clamping. Core and coil assembly is more stable, reducing vibration and mechanical stress.
- Longer Service Life - Better materials and structural improvements lead to extended service life, often reaching 20-30 years under proper conditions.
Technical Parameters
| Rated Capacity (kVA) | Vector Group | Voltage Combination | No-load Loss | Load Loss | No-load Current | Impedance |
| 30 | Yyn0 / Dyn11 | 10 6.3 6 | ±5% ±2X2.5% | 0.4 | 80 | 630 | 1.5 | 4.0 |
| 50 | | | | | 100 | 910 | 1.3 | |
| 63 | | | | | 110 | 1090 | 1.2 | |
| 80 | | | | | 130 | 1310 | 1.2 | |
| 100 | | | | | 150 | 1580 | 1.1 | |
| 125 | | | | | 170 | 1890 | 1.1 | |
| 160 | | | | | 200 | 2310 | 1.0 | |
| 200 | | | | | 240 | 2730 | 1.0 | |
| 250 | | | | | 290 | 3200 | 0.9 | |
| 315 | | | | | 340 | 3830 | 0.9 | |
| 400 | | | | | 410 | 4520 | 0.8 | |
| 500 | | | | | 480 | 5410 | 0.8 | |
| 630 | | | | | 570 | 6200 | 0.6 | 4.5 |
